TECHNICAL DATA

Current Ratings (A) :
Aluminium conductor series from 630A up to 5000A
Copper conductor series from 800A up to 6300A
Number of Conductors: 3, 4, 4.5, 5 or 6
Structure:
• 3 Hours of fire barrier resistance
(Accordance with ISO 834)
• Clean earth option
• Exterior environment IP 68 protection class
• Corrosion-resistant
• Chemical-resistant
• Pest-resistant
• Usable in tropical environments
• Has high mechanical strength
• Without stack effect
• Highly resistant to short circuit
• Fire-resistant
• Current continuity under fire conditions
Product Standard: IEC 60068-3-3, IEC 60068-2-57

APPLICATION

  • Galleries between Transformer and Panel
  • Oil and Gas Plants
  • Cement Plants
  • Power Plants
  • Harbors and Shipyards
  • Food Premises
  • Tunnels and Underpasses

ADVANTAGES

  • High short circuit resistance due to compact construction
  • Less voltage drop in comparison to cable systems
  • Special alloy metal enclosure provides higher mechanical
    strength and causes less electromagnetic interference.
  • Better cooling capability
  • High resistance to fire
  • Seismic resistance
  • Protection Degree (IP55 standard and IP67 optional)
  • Requires less space in comparison to cable systems
